Rickie,Tom,question

Attachment 167225 The black and the bright red wire are not under foil,the purple and light red are wrap under foil together ,then you have the naked wire which should be ground, then you have the yellow and brown wire wrap together under foil , then you have the foil wrapping all the wires with the silver inside and blue outside, the opposite of other wrapping, my question is the yellow is right SI and the light red that is wrap with the purple is left SI ,am I right??

Tranducer cable repair

Tom's link shows the wire color designations...

This diagram also shows the pin designations for those same wires in Tom's link...

http://i477.photobucket.com/albums/r...psb4bd5280.jpg

Rickie

I don't know if it will help in your project...but a lot of blue water boys use this for cable splicing...

http://www.airmartechnology.com/uplo.../17-037-01.pdf

Rickie
